Hoods & Housings B Series (32B / 48B)Size 32B
32B Metal Hoods & Housings — Side & Top Entry, Surface Mount & Cable-to-Cable · 4-Bolt / 2-Lever + Protection Cover (IP65)
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
H32B-BK-2L
H32B-MCV-4B/2
H32B-SE-4B-M32
H32B-SE-4B-M40
H32B-SE-4B-M50
H32B-SE-4B-PG29
H32B-SE-4B-PG36
H32B-SE-4B-PG42
H32B-SE-4B-G2
H32B-TE-4B-M32
H32B-TE-4B-M40
H32B-TE-4B-M50
Each datasheet image is a full catalog page (contact arrangement, panel cut-out, dimensions, order table and parameters). Inserts ship as male (M) or female (F) halves and are ordered separately. Terminal-type suffix: none = screw, C = crimp, S = cage-clamp, Z = quick-lock (push-in), SS = double cage-clamp (two conductors per contact). 16A crimp contacts (CESM/CEGM silver/gold series), crimp tool TL02G and removal tool TL01 are shared accessories listed on the datasheet pages and will be catalogued in the accessories batch.
Technical Parameters
| Protection | IP65 |
| Compatible Insert Size | 32B |
| Material | Zinc / aluminium die-cast |
| Colour | Grey |
| Locking Element | Metal spring lever (galvanized / nickel-plated steel) |
| Temperature Range | -40°C ... +125°C |
| Standards | DIN EN 60529 |
| Seal | NBR |
| Housing Types | side-entry hood, top-entry hood, bulkhead housing, surface-mount housing, cable-to-cable housing, metal protection cover |
| Locking | 4-Bolt, 2-Lever |
| Threads | M32 / M40 / M50 / PG29 / PG36 / PG42 / G2 |
Datasheet
