Lock Nuts
Polyamide Lock Nut (Grey / Black)
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
WNAP-PG7G/S
WNAP-PG9G/S
WNAP-PG11G/S
WNAP-PG13.5G/S
WNAP-PG16G/S
WNAP-PG21G/S
WNAP-PG29G/S
WNAP-PG36G/S
WNAP-PG42G/S
WNAP-PG48G/S
WNAP-PG7B/S
WNAP-PG9B/S
Each datasheet image is a full catalog page (contact arrangement, panel cut-out, dimensions, order table and parameters). Inserts ship as male (M) or female (F) halves and are ordered separately. Terminal-type suffix: none = screw, C = crimp, S = cage-clamp, Z = quick-lock (push-in), SS = double cage-clamp (two conductors per contact). 16A crimp contacts (CESM/CEGM silver/gold series), crimp tool TL02G and removal tool TL01 are shared accessories listed on the datasheet pages and will be catalogued in the accessories batch.
Technical Parameters
| Material | Polyamide (Nylon 66) |
| Colours | Grey / Black |
| Function | Counter / lock nut for fixing glands and plugs into a panel |
| Temperature Range | -40°C … +100°C |
| Threads | PG7–PG48 / M12–M63 × 1.5 |
| Thickness | 5.0–8.0 mm |
