Outer-Thread Metal Conduit Connector — Zinc Alloy
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
WNC-PG9/D10
WNC-PG11/D12
WNC-PG13.5/D15
WNC-PG16/D15
WNC-PG21/D20
WNC-PG29/D25
WNC-PG29/D32
WNC-PG36/D38
WNC-PG42/D38
WNC-PG48/D51
WNC-M16/D8
WNC-M16/D10
Each datasheet image is a full catalog page (contact arrangement, panel cut-out, dimensions, order table and parameters). Inserts ship as male (M) or female (F) halves and are ordered separately. Terminal-type suffix: none = screw, C = crimp, S = cage-clamp, Z = quick-lock (push-in), SS = double cage-clamp (two conductors per contact). 16A crimp contacts (CESM/CEGM silver/gold series), crimp tool TL02G and removal tool TL01 are shared accessories listed on the datasheet pages and will be catalogued in the accessories batch.
Technical Parameters
| Material | Zinc alloy, zinc-plated or chromium-plated |
| Feature | One end connects to flexible tube, the other thread end to enclosure/equipment; compact, corrosion-resistant |
| Applications | Electromotor, cable bridge frame, electrical engineering, electric control cabinets |
| Tubing Size | D8–D51 |
| Threads | PG9–PG48 / M16–M36 |
Datasheet
