Conduit / Tube Connectors
Quick Conduit Connector — Nylon 6
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
WNCP-PG7B
WNCP-PG9B
WNCP-PG11B
WNCP-PG13.5B
WNCP-PG16B
WNCP-PG21B
WNCP-PG29B
WNCP-PG36B
WNCP-M12B
WNCP-M16B
WNCP-M18B
WNCP-M20B/AD18.5
Each datasheet image is a full catalog page (contact arrangement, panel cut-out, dimensions, order table and parameters). Inserts ship as male (M) or female (F) halves and are ordered separately. Terminal-type suffix: none = screw, C = crimp, S = cage-clamp, Z = quick-lock (push-in), SS = double cage-clamp (two conductors per contact). 16A crimp contacts (CESM/CEGM silver/gold series), crimp tool TL02G and removal tool TL01 are shared accessories listed on the datasheet pages and will be catalogued in the accessories batch.
Technical Parameters
| Material | Nylon 6 |
| Colour | Black |
| Feature | Quick push-on connection for corrugated tubing (AD sizes) |
| Temperature Range | -40°C … +120°C |
| Tubing Size | AD10.0–AD54.5 |
| Threads | PG7–PG36 / M12–M63 × 1.5 |
