IO-Link I/O HubsIO-Link16-ch PNPIO-Link
HUB-PI16-N67CC IO-Link Hub · 16× PNP Inputs
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
HUB-PI16-N67CC
Cable lengths can be customized. Coding follows protocol standard: PROFIBUS = B-Code (violet), DeviceNet = A-Code/7-8 (CAN), PROFINET/EtherNet-IP/EtherCAT = D-Code (green, CAT5e), 10G = X-Code (CAT6A).
Technical Parameters
| Channels | 16 |
| Input | 16-channel PNP digital input |
| Ports | 8× M12 I/O ports + 1× M12 IO-Link port |
| Operating Voltage | 18 – 30 VDC |
| Typical Operating Voltage | 24 V |
| Current Consumption No Load | 20 mA max |
| Power Supply Current | 200 mA × 8 |
| Io Link Type | Device, IO-Link v1.1 |
| Communication Speed | COM2 (38.4 kbps) |
| Min Cycle Time | 3.2 ms |
| Process Data | Input 2 bytes / Output 0 bytes |
| Vendor Id | 1084 (0x043C) |
| Iodd | Hub-PI16D-20220513-IODD1.1.zip |
| Input Filters | Per-channel configurable: debounce 0–50 ms, pulse extension (hold) 0–500 ms, input inversion — individual / collective / grouped setting modes |
| Firmware Upgrade | Online upgrade via IO-Link (BLOB transfer) |
| Diagnostics | Overcurrent and supply over/under-voltage events; LED status indication; locate (flash) function |
| IP Rating | IP67 |
Datasheet
