Inserts & Grommets
KT Small Inserts (20×20)
20×20 mm split sealing inserts: single-cable KT 2–17, multi-hole KT 2/x and 4/x, plus BTK frame and ST sealing plugs.
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
BTK (099041251)
KT 2 (099039934) — 2-3 mm
KT 3 (099041203) — 3-4 mm
KT 4 (099041204) — 4-5 mm
KT 5 (099041205) — 5-6 mm
KT 6 (099041206) — 6-7 mm
KT 7 (099041207) — 7-8 mm
KT 8 (099041208) — 8-9 mm
KT 9 (099041209) — 9-10 mm
KT 10 (099041210) — 10-11 mm
KT 11 (099041211) — 11-12 mm
KT 12 (099041212) — 12-13 mm
Part numbers are enumerated from the official sample book; many frames accept the modular KT/KTP/KTB/CM insert range (see Inserts & Grommets and the KBD/KML module pages). IP ratings depend on correct insert selection and gasket use. All dimensions in mm.
Technical Parameters
| Material | Synthetic rubber (elastomer) |
| Flame Class | UL94-V0 |
| IP Rating | IP54 |
| Operating Temp. | -40 to +90 °C |
| Module Size | 20×20 mm |
| Cable Range | 2 to 17 mm |
Datasheet
