EMC Metal Cable Gland — Nickel-Plated Brass (IP68)
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
WNAC-PG7(D3-6.5)
WNAC-PG9(D4-8)
WNAC-PG11(D5-10)
WNAC-PG13.5(D6-12)
WNAC-PG16(D8-14)
WNAC-PG21(D13-18)
WNAC-PG29(D18-25)
WNAC-PG36(D22-32)
WNAC-PG42(D30-38)
WNAC-M12(D3-6.5)
WNAC-M16(D4-8)
WNAC-M18(D5-10)
Each datasheet image is a full catalog page (contact arrangement, panel cut-out, dimensions, order table and parameters). Inserts ship as male (M) or female (F) halves and are ordered separately. Terminal-type suffix: none = screw, C = crimp, S = cage-clamp, Z = quick-lock (push-in), SS = double cage-clamp (two conductors per contact). 16A crimp contacts (CESM/CEGM silver/gold series), crimp tool TL02G and removal tool TL01 are shared accessories listed on the datasheet pages and will be catalogued in the accessories batch.
Technical Parameters
| Material | Nickel-plated brass |
| Seal | Nylon 66 and NBR |
| Feature | EMC — 360° spring-contact shield termination |
| Protection | IP68 (with O-ring) |
| Temperature Range | -40°C … +100°C, short-term +120°C |
| Threads | PG7–PG42 / M12–M63 × 1.5 |
| Clamping Range | 3–6.5 mm up to 37–44 mm |
