Metal Waterproof Cable Gland — Nickel-Plated Brass (PG / Metric, IP68)
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
WNA-PG7(D3-6.5)
WNA-PG9(D4-8)
WNA-PG11(D5-10)
WNA-PG13.5(D6-12)
WNA-PG16(8-14)
WNA-PG21(D13-18)
WNA-PG29(D18-25)
WNA-PG36(D22-32)
WNA-PG42(D31-38)
WNA-PG48(D37-44)
WNA-M12(D3-6.5)
WNA-M14(D3-6.5)
Each datasheet image is a full catalog page (contact arrangement, panel cut-out, dimensions, order table and parameters). Inserts ship as male (M) or female (F) halves and are ordered separately. Terminal-type suffix: none = screw, C = crimp, S = cage-clamp, Z = quick-lock (push-in), SS = double cage-clamp (two conductors per contact). 16A crimp contacts (CESM/CEGM silver/gold series), crimp tool TL02G and removal tool TL01 are shared accessories listed on the datasheet pages and will be catalogued in the accessories batch.
Technical Parameters
| Material | Nickel-plated brass |
| Seal | Nylon 6 and NBR |
| Protection | IP68 (with O-ring) |
| Temperature Range | Static -40°C … +100°C / Dynamic -20°C … +80°C |
| Threads | PG7–PG48 / M12–M63 × 1.5 |
| Clamping Range | 3–6.5 mm up to 37–44 mm |
Datasheet
