M12 Mating Connectors & Cordsets (for M8 4/6-Port Boxes)
Field-wireable and pre-molded M12 8-pin connectors plus matching trunk cable for M8 boxes with M12 trunk.
Download the complete PDF catalogue for full specifications and ordering details.
Part Numbers
M12-F08S-PG9
M12-F08A-PG9
M12-F08S-6P-2.0PVC/GY
M12-F08A-6P-2.0PVC/GY
M12-F08S-6P-2.0PUR/GY
M12-F08A-6P-2.0PUR/GY
M12-F08S-8P-2.0PVC/GY
M12-F08A-8P-2.0PVC/GY
M12-F08S-8P-2.0PUR/GY
M12-F08A-8P-2.0PUR/GY
PVC-6C-3.0/GY
PUR-6C-3.0/GY
Standard cable length 5.0 m, customizable in 0.5 m increments. Channel codes: 1CN/1CW single, 2CN/2CW double (M8); 1C single, 2C double (M12). Trunk codes: 5.0PVC/PUR integrated cable, M12/M23 plug, PW bare PCB header, TB screw-terminal hood. Colors: GY/GR Gray. Reference pages 03-06 cover the product overview, model numbering and mounting dimensions.
Technical Parameters
| IP Rating | IP67 |
| Std. Cable Length | varies (see datasheet) |
Datasheet
